JE-LiYCY…Bd

JE-LiYCY…Bd

TS 13767 , DIN VDE 0815

These are communication and information transmission cables produced according to TS 13767
and VDE 0815 standards. It is designed to be used in industrial electronics, computer systems,
indoor communication systems, audio, security and fire alarm systems. The screen provides
protection against electromagnetic effects from the environment. It is not suitable for use
outdoors or buried directly under the ground.

Category: COMMUNICATION AND INFORMATION TRANSMISSION CABLES

Description

CONSTRUCTION

Conductor: Electrolytic copper (EN/IEC 60228, DIN EN 60228 VDE 0295- Sınıf 2)
Insulation: PVC (EN 50290-2-21 , DIN VDE 0207-4)
Core Identification: TS 13767 / VDE 0815
Stranding: Groups stranded in layers
Wrapping: Polyester Tape
Screen: Tinned Copper Braid
Outer Sheath: PVC (EN 50290-2-22 , DIN VDE 0207-5)
Outer Sheath Colour: RAL 7001 Grey (Other colours on request)

AVAILABLE OPTIONS ON REQUEST

– HFFR Insulation , HFFR Outer Sheath
– EN 50575 CPR compliant

Datasheet
