RE-2Y(St)HSWAH Pimf Cu-PE-IS-OS-LSZH-SWA-LSZH

ENSTRÜMANTASYON KABLOLARI

RE-2Y(St)HSWAH Pimf Cu/PE/IS/OS/LSZH/SWA/LSZH

EN 50288-7

EN 50288-7 standardına göre üretilmiş enstrümantasyon kablolarıdır. Analog ve dijital sinyallerin iletiminde, kimya endüstrisinde, endüstriyel sinyalizasyon ve proses kontrol devrelerinde, petrokimya endüstrisi gösterge panelleri, elektrik ölçüm cihazlarında ve
gaz istasyonlarında kullanılmak üzere tasarlanmıştır.

Kategoriler: ENSTRÜMANTASYON KABLOLARI

Açıklama

KABLO YAPISI

İletken: Elektrolitik bakır (EN/IEC 60228 )
Yalıtım: PE (EN 50290-2-23)
Damar Renkleri: Beyaz (Siyah numaralı) veya Siyah (Beyaz Numaralı)
Bireysel Ayırıcı: Polyester Bant
Bireysel Ekran: Alüminyum/Polyester Bant + Kalaylı Bakır Toprak Teli
Büküm: Ekranlanmış perler katlar halinde bükülür
Genel Ayırıcı: Polyester Bant
Genel Ekran: Alüminyum/Polyester Bant + Kalaylı Bakır Toprak Teli
Dış Kılıf: LSZH (EN 50290-2-27)
Zırh: Galvanizli Yuvarlak Çelik Tel
Dış Kılıf: LSZH (EN 50290-2-27)
Dış Kılıf Rengi: RAL 9005 Siyah , RAL 5015 Mavi ( Diğer renkler isteğe bağlı)

TALEP ÜZERİNE SEÇENEKLER

– 500 V versiyon
– 0,6/1 kV versiyon
– XLPE Yalıtım
– Üçlü , Dörtlü büküm
– SWB / Q versiyon
– STA versiyon
– PVC Dış Kılıf
– UV dayanımlı Kılıf
– Anti Termit / Anti Rodent
– EN 50575 CPR Uyumluluğu
